JetStream Gigabit L2 s 24 priključki in s 4 režami SFP mrežno stikalo
Polni gigabitni vmesniki: 24x gigabitna vrata RJ45 in 4x gigabitna SFP reža zagotavljajo visoke hitrosti povezave.
Vgrajen v Omada SDN: Zero-Touch Provisioning (ZTP)*, centralizirano upravljanje v oblaku in inteligentno spremljanje.
Centralizirano upravljanje: dostop v oblaku in aplikacija Omada za izjemno udobje in enostavno upravljanje.
Statično usmerjanje: pomaga usmerjati notranji promet za učinkovitejšo uporabo omrežnih virov.
Robustne varnostne strategije: vezava vrat IP-MAC, ACL, zaščita vrat, DoS Defend, nadzor nad nevihto, DHCP Snooping, 802.1X in drugo.
Optimizirajte glasovne in video aplikacije: L2/L3/L4 QoS in vohunjenje IGMP.
Samostojno upravljanje: Web, CLI (konzolna vrata, Telnet, SSH), SNMP, RMON in Dual Image prinašajo močne zmogljivosti upravljanja
Podatki proizvajalca:
TP-Link Networks Hungary Kft
Közraktár u. 30
Budapest, HU-1093
Madžarska
sales.hu@tp-link.com
Proizvajalčeva koda: SG3428
EAN koda: 6935364010713
Proizvajalec: TP-LINK
Namestitev:: rack / namizni
Vrsta stikala:: Managed
Standard:: /
Vmesniki:: 24x 10/100/1000Mbps, 4x Gigabit SFP Slot, 1x RJ45 konzola, 1x Micro USB
Zmogljivost::
preklopna zmogljivost: 56 Gbps
število paketov na sekundo: 41,66 Mpps
Programske funkcije::
Quality of Service
– 8 priority queues
– 802.1p CoS/DSCP priority
– Queue scheduling
– SP (Strict Priority)
– WRR (Weighted Round Robin)
– SP+WRR
– Bandwidth Control
– Port/Flow based Rating Limiting
– Smoother Performance
– Action for Flows
– Mirror (to supported interface)
– Redirect (to supported interface)
– Rate Limit
– QoS Remark
L2 and L2+ Features
– Link Aggregation
– Static link aggregation
– 802.3ad LACP
– Up to 8 aggregation groups and up to 8 ports per group
– Spanning Tree Protocol
– 802.1d STP
– 802.1w RSTP
– 802.1s MSTP
– STP Security: TC Protect, BPDU Filter, BPDU Protect, Root Protect, Loop Protect
– Loopback Detection
– Port-based
– VLAN based
– Flow Control
– 802.3x Flow Control
– HOL Blocking Prevention
– Mirroring
– Port Mirroring
– CPU Mirroring
– One-to-One
– Many-to-One
– Tx/Rx/Both
L2 Multicast
– Supports 511 (IPv4, IPv6) IGMP groups
– IGMP Snooping
– IGMP v1/v2/v3 Snooping
– Fast Leave
– IGMP Snooping Querier
– IGMP Authentication
– IGMP Authentication
– MVR
– MLD Snooping
– MLD v1/v2 Snooping
– Fast Leave
– MLD Snooping Querier
– Static Group Config
– Limited IP Multicast
– Multicast Filtering: 256 profiles and 16 entries per profile
VLAN
– VLAN Group
– Max 4K VLAN Groups
– 802.1q Tagged VLAN
– MAC VLAN: 12 Entries
– Protocol VLAN: Protocol Template 16, Protocol VLAN 16
– GVRP
– VLAN VPN (QinQ)
– Port-Based QinQ
– Selective QinQ
– Voice VLAN
Access Control List
– Time-based ACL
– MAC ACL
– Source MAC
– Destination MAC
– VLAN ID
– User Priority
– Ether Type
– IP ACL
– Source IP
– Destination IP
– Fragment
– IP Protocol
– TCP Flag
– TCP/UDP Port
– DSCP/IP TOS
– User Priority
– Combined ACL
– Packet Content ACL
– IPv6 ACL
– Policy
– Mirroring
– Redirect
– Rate Limit
– QoS Remark
– ACL apply to Port/VLAN
Security
– IP-MAC-Port Binding
– DHCP Snooping
– ARP Inspection
– IPv4 Source Guard
– IPv6-MAC-Port Binding
– DHCPv6 Snooping
– ND Detection
– IPv6 Source Guard
– DoS Defend
– Static/Dynamic Port Security
– Up to 64 MAC addresses per port
– Broadcast/Multicast/Unicast Storm Control
– kbps/ratio/pps control mode
– IP/Port/MAC based access control
– 802.1X
– Port based authentication
– Mac based authentication
– VLAN Assignment
– MAB
– Guest VLAN
– Support Radius authentication and accountability
– AAA (including TACACS+)
– Port Isolation
– Secure web management through HTTPS with SSLv3/TLS 1.2
– Secure Command Line Interface (CLI) management with SSHv1/SSHv2
IPv6
– IPv6 Dual IPv4/IPv6
– Multicast Listener Discovery (MLD) Snooping
– IPv6 ACL
– IPv6 Interface
– Static IPv6 Routing
– IPv6 neighbor discovery (ND)
– Path maximum transmission unit (MTU) discovery
– Internet Control Message Protocol (ICMP) version 6
– TCPv6/UDPv6
– IPv6 applications
– DHCPv6 Client
– Ping6
– Tracert6
– Telnet (v6)
– IPv6 SNMP
– IPv6 SSH
– IPv6 SSL
– Http/Https
– IPv6 TFTP
L3 Features
– 16 IPv4/IPv6 Interfaces
– Static Routing
– 48 static routes
– Static ARP
– 316 ARP Entries
– Proxy ARP
– Gratuitous ARP
– DHCP Server
– DHCP Relay
– DHCP L2 Relay
Management
– Web-based GUI
– Command Line Interface (CLI) through console port, telnet
– SNMPv1/v2c/v3
– Trap/Inform
– RMON (1, 2, 3, 9 groups)
– SDM Template
– DHCP/BOOTP Client
– 802.1ab LLDP/LLDP-MED
– DHCP AutoInstall
– Dual Image, Dual Configuration
– CPU Monitoring
– Cable Diagnostics
– EEE
– Password Recovery
– SNTP
– System Log
Advanced Features
– Support Omada Hardware Controller (OC200/OC300), Software Controller, Cloud-Based Controller
– Automatic Device Discovery
– Batch Configuration
– Batch Firmware Upgrading
– Intelligent Network Monitoring
– Abnormal Event Warnings
– Unified Configuration
– Reboot Schedule
– ZTP (Zero-Touch Provisioning)
Dimenzije:: 440 x 180 x 44 mm
Garancija: 36 mesecev
Vsebina paketa:: napajalni kabel, CD, rackmount kit, gumijaste noge
Zaloga: Po naročilu (2–3 dni)
Stanje: Novo
Garancija: 36 mesecev
