Maximum number of SMP processors:
– 1
Processor socket:
– LGA 1700
Compatible processor series:
– Intel Core i5
– Intel Core i7
– Intel Core i9
Processor manufacturer:
– Intel
Audio output channels:
– 7.1 channels
Motherboard chipset:
– Intel Z790
Audio chip:
– Realtek ALC897
Motherboard chipset family:
– Intel
Motherboard form factor:
– ATX
Windows operating systems supported:
– Windows 10 x64
– Windows 11 x64
Number of memory slots:
– 4
Memory slots type:
– DIMM
Supported memory types:
– DDR5-SDRAM
Maximum internal memory:
– 128 GB
Memory channels:
– Dual-channel
Depth:
– 244 mm
Width:
– 305 mm
Ethernet interface type:
– 2.5 Gigabit Ethernet
Ethernet LAN:
– Yes
LAN controller:
– Dragon RTL8125BG
Wi-Fi:
– No
RGB LED pin header:
– Yes
ATX Power connector (24-pin):
– Yes
Front panel audio connector:
– Yes
CPU fan connector:
– Yes
USB 2.0 connectors:
– 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
– 2
USB 3.2 Gen 2 (3.1 Gen 2) connectors:
– 1
Thunderbolt headers:
– 1
Number of SATA III connectors:
– 4
TPM connector:
– Yes
EPS power connector (8-pin):
– Yes
BIOS type:
– UEFI AMI
Supported storage drive interfaces:
– M.2, SATA III
RAID levels:
– 10
– 0
– 1
– 5
RAID support:
– Yes
Headphone outputs:
– 1
S/PDIF out port:
– Yes
Ethernet LAN (RJ-45) ports:
– 1
DisplayPort version:
– 1.4
USB 2.0 ports quantity:
– 6
Microphone in:
– Yes
HDMI ports quantity:
– 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
– 2
DisplayPorts quantity:
– 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
– 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
– 2
PCI Express x16 (Gen 4.x) slots:
– 2
PCI Express x16 (Gen 5.x) slots:
– 1
PCI Express x1 (Gen 3.x) slots:
– 1
Number of M.2 (M) slots:
– 1
Zaloga: Po naročilu (2–3 dni)
Stanje: Novo
Garancija: 24 mesecev
